Torno CNC

1

Processing project

Processing a rib groove roller (crescent rib, high rib groove etc.)

Marks the engraving

2

Workpiece material / type

Common material, high speed steel roll, composite roller,

tungsten carbide roll ring

3

Applicable screw-thread

mm

Φ6~~Φ50

4

Max. diameter of workpiece

mm

Φ500

5

Min. Diameter of workpiece

mm

Φ100

6

Max. length of workpiece

mm

2500

7

Cutting type

Milling-head swinging cutting and “fly-cutter” cutting

8

Headstock spindle bore-hole

MOS 5

9

Headstock chuck

mm

4-jaw chuck φ400

10

The fly-cutter spindle speed

/ power

rpm /kw

10~450(fly-cutter)/ 2.5

11

The milling head spindle

speed / power

rpm /kw

2000~8000(Milling-head)/ 2.5

12

Diameter of tailstock sleeve

mm

180

13

Tailstock spindle bore-hole

MT5#

14

The minimal unit

of axis feed

mm

0.001

15

System control axis

4 axis（X、Y、Z、C）

16

Electric box air conditioner

W

500

17

Cooling pump motor

W

90

18

Total Gross weight

kg

4700

19

Overall dimensions

(L×W×H)

mm

3850×1350×1400

20

CNC system

SINUMERIK 808D 4 axis、Servo drive
